Quality Control & Inspection
This training offers a complete guide to 3D scan-based inspection using Geomagic Control X. It is ideal for quality engineers and metrology professionals seeking to validate parts against design specifications. The course takes you through alignment, dimensional inspection, GD&T analysis, and report generation, providing you the tools to implement a robust digital inspection workflow.
Training Topics
Introduction to metrology and digital inspection workflows
Overview of Geomagic Control X interface and tools
Importing scan and CAD data for inspection
Alignment techniques: 3-2-1, best-fit, datum-based
Mesh to CAD deviation analysis
Creating reference geometry and measurement features
Dimensional inspection of points, lines, circles, planes, and features
Applying GD&T tolerances (flatness, parallelism, true position, etc.)
Inspecting large parts using photogrammetry-based workflows
Creating section views and custom measurement plans
Using templates for repetitive inspections
Generating visual and PDF-based inspection reports
